Air Operated Shot Blasting Machine
  More Images

Air Operated Shot Blasting Machine

Price Range : ₹ 35k - 20Lakh

Abrasive Capacity
150 Kg – 1000 Kg
Compressed air required
30 - 217 cfm. At 80 PSI
Machine Type
Manual /Fully Automatic / Semi Automatic
Material Construction
Mild Steel
Blast Principle
Suction Blasting, Pressure Blasting, Wet Blasting
Rust & Corrosion Removal, Paint Removal, Deburring, Etching, Engraving, Dust Control
Dust Collector with cabinet & booth
Fabric bag dust collector/ reverse pulse jet pleated filter dust collector.
Filter / Bag Cleaning
Motorized & Manually Shaking, Reverse Pulse Jet Cleaning
Payment Method :
Transportation Mode :
Air Transport
Sea Transport
Land Transport
  •   Air operated shot blasting Machines can help you create an oil-free air blast atmosphere.
  •   To keep the shot blasting system working, a dry air operated shot blasting machine is required.
  •   With a limited airflow direction, this technique is ideal for cleaning various machines and their components.
Rating & Video

4.5 Star Rating by our Precious Clients

Leading Supplier & Exporter
Leading Supplier & Exporter

Trustseal Verified
Trustseal Verified

ISO Certified
ISO Certified


Air Operated Shot Blaster Machine

In Air Operated Shot Blasting Machine shot media is mixed with compressed air, it's known as Pneumatic Shot Blasting Machine. According to customers need air operated shot blasting machine is available in different sizes and types - At the industrial level - a Portable shot blasting machine. House Purpose - Blasting Cabinet, Vacuum Blasting Machine, Blast Room.

AirOperated shot blasting machines can use the form of a shot blasting room or a shot blasting cabinet, the blasting abrasive media is pneumatically stimulated by compressed air and propelled by shot Blasting nozzles onto the component. For special applications a media-water mix can be utilized, this is called wet blasting. In both air-operated shot blasting machine and wet shot blasting machine, the Shot blast nozzles can be installed in fixed positions or can be operated manually or Automatically. The blasting task determines the selection of the abrasive media like sand, shot, grit, and plastic; in most cases, any type of dry or free-running abrasive Material can be utilized.

Specification of Air Operated Shot Blasting Machine

Minimum Order Quantity

1 No.


Ambica Enterprises

Production Capacity

7-8 Per Month

Number Of Nozzle


Automation Grade

Manual, Semi Automatic, Fully Automatic

Tungsten Carbide Nozzle Size


Blast Hose Length

3 Mtr to 30 Mtr

Abrasive Tank Capacity

150-1000 Kg


Mild Steel

Air Operated Shot Blasting Machine Operations

1). For small Component - Shot Blasting Cabinet

2). For large component - Shot Blasting Room System. Low Budget and there is no need for open blasting machines choose Vacuum Blasting Machine is suitable

Types of Air Operated Shot Blasting Machine

The classification of Air Operated Shot blasting machines is very huge, but in India, there are two types of Shot blasting machines that are used.

  • Portable shot blasting machine

  • Cabinet type shot blasting machine

Portable Shot Blasting Machine

As per the name given of this machine, these are movable type shot blasting machines. There is no requirement for extra space at the workplace, it can easily be movable as per the requirement.

For the small to medium-scale industry, this machine is very useful. Industries such as paint transformer manufacturing, pipe manufacture, glass making companies, Automobile industry, powder coating industry, and many more.

According to the capacity of the machine and the rate of cleaning the surface, a portable shot blasting machine is classified. One of the advantages of using a portable shot blasting machine is that any type of abrasive is used.

Most often, for the small-scale industry, it is a more preferable machine for surface cleaning purposes.

Cabinet Type Shot Blasting Machine

This type of machine is specifically designed for large industry purpose with another two additional functions added to this machine that is recycling and collection of junk materials. These machines have a closed cabinet structure. This cabinet is using for cleaning medium and small-sized jobs such as mild steel, stainless steel, glass, handicrafts, wood, casting, and mold. One of the advantages of this machine is to remove scratches or casting mold marks.

According to shapes and size, cabinet shot blasting machine is divided into two types:

Small shot blasting cabinet: - It is used in small casted and fabricated components, broken charges, and small casting. It is further classified into two categories: small shot blasting cabinet and mini shot blasting cabinet

Large Shot blasting cabinet: - It is used in large components such as rods, casting, mould, granite, and fabricated items. It contains a dust collector and dust collector capacity depends on the size of shot blasting cabinets.

Air Operated shot blasting machines Manufacturer in India

Ambica Enterprises is Best Air Operated shot blasting machine manufacturer in India at a low price for sale. we are also Manufacturer, Supplier & Exporter of Sand Blasting Machine, Shot Blasting Machine, Grit blasting Machine, sand Blasting cabinet, pressure blasting cabinet, sand Blasting Nozzle, Sand Blasting Room, grit blasting chamber, thermal Spray gun, Metalizing gun, zinc spray gun, wire arc spray gun, etc in Jodhpur, Rajasthan, India with the best quality for sale. we provide all types and different size air operated shot Blasting machine according to customer needs manually or automatically operated.
