Wire Flame Spray Gun

Price Range : ₹ 45K - 2Lakh

Specifications
Material of Construction
Aluminum, Brass, Bronze, CI Casting, Stainless Steel
Type of Gun
Wire Flame Spray Gun
Compressed Air Required
25 to 30 CFM at 5 bar
Wire feed Size
1.6 mm, 2 mm, 3.17 mm
Input Gas
Oxygen and LPG/ Acetylene
Wire Feed
Pneumatic Air Driven Turbine or Electric drive
Payment Method :
100% T/T NEFT RTGS IMPS
Transportation Mode :
Air Transport
Sea Transport
Land Transport
Applications
  •   The themes that will be sprayed are unaffected by high temperatures, ensuring dimensional and morphological stability as well as the lack of cracks and strength loss.
  •   There are several different coating thicknesses available.
  •   In addition to hard ingredients like metal oxide, nitride, carbide, and other hard elements that offer a high level of wear resistance, the coating also includes harder particles than the original materials.
  •   steel with zinc and aluminum cathodic coatings to prevent corrosion.
  •   Self-bonding and bond coats constructed of composite nickel/aluminum wire.
Rating & Video

4.5 Star Rating by our Precious Clients

Leading Supplier & Exporter
Leading Supplier & Exporter

Trustseal Verified
Trustseal Verified

ISO Certified
ISO Certified

Manufacturer
Manufacturer

Wire Flame Spray Gun uses a single wire that is filled into a wire jet flame. The molten particles are atomized and propelled onto the substrate by the air stream from the jet. These technological aspects, such as feedstock, gun gas composition, flow rate, and energy input, all play a significant effect in the particle-substrate connection. The wire spray material is melted in a gaseous oxygen-fuel flame when using the wire flame spray process. Propane, acetylene, or hydrogen can be used as fuel gas.

Wire Flame Spray Gun is a type of technology for melting wires that uses an oxy-fuel flame. To make a spray of a stream that coats a surface and is sprayed on an entity. a fire Both ferrous and nonferrous materials are sprayed with a spray gun. Rebuilding worn-out elements, conductivity, and anti-corrosion coating are all important uses.

Specifications of Wire Flame Spray Gun

MODEL Name WIRE used DIAMETER WIRE FEEDING GASES USED
12P Aluminum, Zinc,
Stainless Steel,
Copper, Brass,
Bronze etc.
3.17 mm Pneumatic OXYGEN,
PROPANE/ACETYLENE
12P-ED Zinc wire, Aluminium, Copper,
Stainless Steel,
Brass, Bronze NiAl, etc.
1.6/2.3/3.17 mm Electric Motor Oxygen, Acetylene,
Propane, LPG
5-PK Molybdenum 1.6/2.0/2.3 mm Electric Motor Oxygen, Acetylene
14P Zinc, Aluminium, Brass
Stainless Steel,
Copper, Bronze, etc.
3.17 mm Pneumatic OXYGEN,
PROPANE/ACETYLENE

Type of Wire Flame Spray Gun

5M Wire Flame Spray Gun

The 5M Wire flame Spray Gun is designed for large-scale manufacturing with lengthy continuous spray periods and consistent coating quality. It's dependable and cost-effective, with very little downtime. The rate of spray can be adjusted using the external Wire Feed Speed Panel. The 5KM series guns can be maintained quickly and easily, allowing them to resume production with minimal downtime.

11M Wire Flame Spray Gun

The 11M Wire Flame Spray Gun is uniquely engineered to function at high rates, allowing the user to efficiently and economically apply soft wire material to any substrate. The wire feed thumb trigger on the 11M Flame Wire Spray cannon makes it ideal for hand-held or start/stop operation. It was created with soft-wire uses in mind. Hard metals, such as Stainless Steel, Nickel, Bronze, Copper, or Bonderite, will not be sprayed with this gun. It may be used for tiny projects as well as large-area applications, and it's nearly as easy to use as spray painting.

12M Wire Flame Spray Gun

One of the best handguns for spray painting with metalizing wires is the 12M Wire Flame Spray Gun. It includes a forged-aluminum universal gas head that can be adjusted to use any fuel gas. The Wire Flame Spray Gun uses acetylene as the fuel gas to spray 1/8" wire. All typical wire sizes from 3/16" to 20 gauges can be managed with the appropriate accessories.

14M Wire Flame Spray Gun

The 14M Wire Flame Spray Gun is a small wire spray gun that draws wire in with an air turbine, melts it with fuel gas, and then sprays the molten particles onto the substrate. The central wire feed thumb trigger on this flexible rifle makes it ideal for hand-held use. Metals and metal alloys are coated with it.

Advantages Of Wire flame Spray Gun

  • Non-conductive wires can be sprayed.
  • Less fine dust particles are created when spraying making overspray less flammable or explosive.
  • More portable for on-site spraying.
  • Simple to ignite.
  • Easy to operate.
  • High spray rate with low gas consumption.
  • Low maintenance design reduces operating costs.
  • It can be used with both hard and soft wires.
  • Extension modules for internal bore applications.

Wire Flame Spray Gun Manufacturer

Ambica Enterprises is a leading Manufacturer, Supplier & Exporter of Thermal Spray guns, Flame Spray guns, zinc spray guns, metalizing guns Hvof Gun, Arc Spray gun, sand Blasting cabinet, Shot Blasting Machine, Sand Blasting Machine, grit blasting Machine, shot blasting cabinet, Suction Blasting Cabinet, Bench Top Sand Blasting Cabinet, Shot Blasting Room, Sand Blasting Nozzles, and abrasive media, etc in Jodhpur, Rajasthan, India at a low price with the best quality for sale. we have the best quality of guns and Wire Flame Spray Guns price in India.
