Sand Blasting Cabinet 3 photos
Pressure Blasting Cabinet
Sand Blasting Cabinet
ISO 9001:2015 Factory Direct Lifetime Support

Pressure Blasting Cabinet

4.5 — Trusted by industrial buyers
Indicative price range 1.20Lakh - 5Lakh

Pressure Blasting Cabinets works on the Direct Pressure principle of blasting. It uses a pressurized vessel or “blast pot” that holds the abrasive media. In a pressure blast cabinet, the air pressure in the vessel and is maintained to be the same. This means that there is no pressure differential between the blast pot and the blast line this allows the abrasive media to meter into the airstream at the blast pot and then transfer the length of the blast hose and pipe out to the nozzle. Pressure abrasive blasting cabinets equipment has a single hose running to the sand blasting nozzle. Designed specifically for high throughput and demanding applications. It provides advanced features to ensure efficient operation or working and maximum operator comfort while using Pressure Blasting Cabinet.

Cleaning rate 10 sq. mtrs/ hr
Motor Power 1.5 Hp
Machine Type Automatic / Manual
Usage Rust Removal/ Surface Preparation
Technical Data

Specifications of pressure blasting cabinet

Key machine parameters to help you evaluate fitment, throughput, and integration with your production line.

Pressure Blasting Cabinet 7 parameters listed
Cleaning rate 10 sq. mtrs/ hr
Motor Power 1.5 Hp
Machine Type Automatic / Manual
Usage Rust Removal/ Surface Preparation
Pressure 25 CFM at 80 PSI
Voltage 110 Volt
Frequency 60 HZ
Use Cases

Industrial application of pressure blasting cabinet

Typical production environments and component types this machine is engineered to support.

Remove rust, mill scale, heat scale and carbon buildup from metals
Strip paint, powder coating, plating and anodising from parts for rework
Eliminate burrs, parting lines, flashing and other
Defects from castings and injection-molded parts
Extract residual sand from castings
Sand Removal
Tube Cleaning
Beautify steel, stainless steel, aluminum, brass and other metals with a matte finish
Etch artwork and lettering into glass, stone, plastics, metal and other material
Clean release agents and material buildup from molds
Machine Demo

Check out pressure blasting cabinet video

Watch real operating footage to understand process flow, abrasive action, and production capability.

Product Video Pressure Blasting Cabinet
Product Overview

Detailed about pressure blasting cabinet

In-depth technical and commercial information about this machine, applications, and operating advantages.

Complete product brief

Pressure Blaster Cabinet

Pressure Blasting Cabinets works on the Direct Pressure principle of blasting. It uses a pressurized vessel or “blast pot” that holds the abrasive media. In a pressure blast cabinet, the air pressure in the vessel and is maintained to be the same. This means that there is no pressure differential between the blast pot and the blast line this allows the abrasive media to meter into the airstream at the blast pot and then transfer the length of the blast hose and pipe out to the nozzle. Pressure abrasive blasting cabinets equipment has a single hose running to the sand blasting nozzle. Designed specifically for high throughput and demanding applications. It provides advanced features to ensure efficient operation or working and maximum operator comfort while using Pressure Blasting Cabinet.

Process of Pressure Blasting Cabinets

  • High production – By far the greatest benefit to a pressure-fed shot blasting cabinet is that it is 3 – 4 times as fast in cleaning a product surface.
  • Better cleaning ability.
  • It can be used with metallic media.
  • Heavy-duty cast-iron media regulator for consistent flow without clogging.

Specifications of Pressure Blasting Cabinet :

WORKING CHAMBER

Height 600mm
Width 600mm
Depth 600mm

Door Opening

Height 500mm
Width 500mm

Overall Dimensions

height 1660mm
width 800mm
depth 1500mm

Dust Collector(Fabric Bag Type Manual Shaking)

Fan Motor 0.5h.p
Fan capacity 200c.f.m
Filter cloth Area 1.0 sq. mt.
Boron carbide Nozzle Short  6mm
Pressure gauge, air regulator &
Moisture separator fitted		 one no. each
Footswitch & door limit switch provided for safety interlocking
Compressed air required at 80 PSI
(for blasting machine only)		 55 c.f.m
Abrasive storage capacity 28(1)ltrs. (CFT)
Abrasive feed  Direct pressure
Recommended Abrasive Size 30 mesh to 100 mesh

Our pressure blasting cabinets provide the cleaning efficiency of an outdoor portable blaster contained within the confines of a bead blasting cabinet. Pressure blasting Cabinet Price in India depends on work-piece size, If the work-piece size is small then need a Pressure small blasting cabinet. If the work-piece size will large then sand blasting cabinets size will be large, so the cost will depend on the size of the blast cabinet. Pressure blasting Cabinet Manufacturer can reduce cost as per component size.

Pressure blasting cabinet price in India

Pressure blasting cabinet price in India. We manufacturer and supplier of Sand Blasting Machine, Sand Blasting Cabinet, shot blasting machine, grit blasting machine, pressure blasting cabinet, Suction Blasting Cabinet, thermal Spray gun, metalizing gun, flame Spray Gun, zinc spray gun, arc Spray gun at low price in all cities: Delhi, Mumbai, Pune, Rajkot, Kolapur, Vadodra, Surat, Chennai, Kolkata, Assam, Jaipur, Kota, Jodhpur, Udaipur, Gandhinagar, Barmer, and all cities. blasting cabinet for sale area is all south cities in India, Cities are Bangalore, Pune, Coimbatore, Chennai, etc. pressure sandblast cabinet from Ambica Enterprises, automate production sequences and improve the work environment.

The Ambica Advantage

Why Buyers Choose Us

End-to-end support from machine selection to commissioning and after-sales service.

Custom Engineering

Configurations tailored to your component size, material, and surface finish targets.

Quality Tested

Pre-dispatch performance checks for blasting efficiency, safety, and reliability.

Export Ready

Documentation and logistics support for domestic and international shipments.

Dedicated Support

Technical guidance for installation, operation, spares, and maintenance.

FAQs

Frequently Asked Questions

Answers about this machine, installation, and support.

Pressure Blasting Cabinet is engineered for As per client requirement, Made in India, Ambica Enterprises, 2-3 Weeks within sand blasting cabinet workflows. It helps remove scale, rust, and contaminants while improving surface profile for coating or further processing. Ambica configures chamber size, abrasive system, and recovery based on your component geometry and daily output.

The typical price range for Pressure Blasting Cabinet is 1.20Lakh - 5Lakh. Final quotation depends on machine size, automation level, dust collector capacity, and optional accessories. Share your component dimensions and production target to receive an engineering-led estimate with scope clarity.

Yes. Ambica can tailor Pressure Blasting Cabinet for your material type, part size, loading method, and finish requirement. Customization may include table or hanger design, blast wheel or nozzle layout, abrasive recovery, and electrical controls. Our team reviews your sample parts and cycle time before recommending the right build.

Installation planning, foundation guidance, and commissioning support are available for Pressure Blasting Cabinet. We assist with alignment, trial runs, operator orientation, and basic troubleshooting so production can start safely. Remote and on-site support options can be discussed at the time of order confirmation.

After-sales support for Pressure Blasting Cabinet includes spare parts guidance, wear-part replacement schedules, and technical assistance for performance optimization. Our service team helps with abrasive selection, preventive maintenance, and uptime improvement across the machine lifecycle.
